Portable Full Automatic Mobile Concrete Batching Plant for construction
Easy to Move: Fully assembled for convenient relocation and installation.
High Production Efficiency: Stable equipment performance ensures high productivity.
User-friendly: Reasonable design with simplified operation.
Energy-saving: Emphasis on energy conservation in design to reduce consumption.
Multi-unit Synchronized Production: Suitable for parallel operation of multiple units to enhance efficiency.
Eco-Friendly Production: Compliant with global environmental standards for sustainable concrete batching.
- Overview
- Specifications and Parameters
- Application Scenarios
- FAQ
- Recommended Products
Product Overview
Welcome to our advanced mobile concrete batching plant solutions, where cutting-edge engineering meets unrivaled operational efficiency. Our mobile concrete batching plants are engineered to deliver a sleek, modern, and highly integrated production system, while ensuring exceptional durability, precision, and reliability for every construction project.
Designed as a fully self-contained unit, our mobile concrete batching plants integrate aggregate feeding, precise weighing, high-performance mixing, and material conveying into one compact, trailer-mounted structure. This streamlined design eliminates the need for complex on-site foundation construction, enabling rapid deployment and seamless relocation between job sites with minimal downtime.
Built with robust high-strength steel frameworks and wear-resistant components, our plants feature a stable, long-lasting structure that withstands rigorous daily use and challenging working conditions. Equipped with an advanced automatic control system, they achieve fully automated operation with precise weighing accuracy, guaranteeing consistent, high-quality concrete output batch after batch.
The twin-shaft forced mixer at the core of our system ensures thorough, uniform mixing of all raw materials, while the intuitive control interface simplifies operation and reduces manual intervention. Whether you are a contractor, project manager, or construction enterprise, our mobile concrete batching plants provide a dependable, efficient solution for delivering consistent concrete production performance.
Specifications and Parameters
|
Model |
YHZS30 |
YHZS45 |
YHZS60 |
YHZS90 |
YHZS120 |
|
Theoretical production capacity |
30m³/h |
45m³/h |
60m³/h |
90m³/h |
120m³/h |
|
Host |
JS500 |
JS750 |
JS1000 |
JS1500 |
JS2000 |
|
Batching Machine |
PLD800 |
PLD1200 |
PLD1600 |
PLD2400 |
PLD3200 |
|
Feeding Capacity(L) |
800 |
1200 |
1600 |
2400 |
3200 |
|
Discharge Capacity(L) |
500 |
750 |
1000 |
1500 |
2000 |
|
Standard Discharge Height(m) |
0.8 |
0.8 |
0.8 |
0.8 |
0.8 |
|
Cycle cycle |
60 |
60 |
60 |
60 |
60 |
|
Overall Dimensions(mm)（L*W*H) |
8600×1850×3200 |
9600×1850×3200 |
12500×2100×3200 |
13500×2100×3200 |
14500×2200×3200 |
|
Aggregate Weighing System Accuracy |
±2% |
±2% |
±2% |
±2% |
±2% |
Application Scenarios
 |
60m³/h / Infrastructure |
|
120m³/h / Mining Area |
 |
|
|
90m³/h / Remote areas |
Advantages：
Flexible Mobility & Fast Commissioning
Integrated Structure & Small Footprint
Cost Saving & High ROI
Stable Performance & Reliable Quality
Intelligent Operation & Eco Production
FAQ
Q：Is transportation and relocation convenient?
A：Integrated modular design allows direct towing by tractor without major disassembly. It features fast transfer, easy assembly and flexible site migration.
Q：Is its output and quality the same as stationary type?
A：Equipped with standard mixer and high-precision weighing system. The mixing quality and proportion accuracy are consistent with stationary plants.
Q：What certifications do your machines have?
A：All our equipment meets ISO9001 and CE standards. We can also provide additional certifications upon request for specific markets.
Q：Can I visit your factory?
A：Welcome! We arrange factory tours with prior appointment - complete with equipment demonstrations
Q：How do you ensure quality?
A：Our 3-step quality control:
- Component inspection
- Factory acceptance test
- Pre-shipment verification
Minimum order quantity ：
1 set
Service Assurance ：
We deliver all-round after-sales guarantee for concrete batching and mixing equipment, covering professional service, technical backup, parts supply and timely maintenance, to keep your equipment running steadily all the time.
Professional Installation and Commissioning
Professional engineers provide one-stop on-site installation, assembly and commissioning upon equipment arrival. We fine-tune operational parameters to bring the unit to optimal working condition in minimal time.
Timely Fault Maintenance and Repair
We implement a rapid after-sales response system. Our technical team offers immediate remote guidance to resolve minor equipment faults online. For complex malfunctions requiring on-site service, we arrange professional engineers for prompt arrival, minimizing downtime and project losses.
Original Factory Spare Parts Supply
We provide 100% original factory spare parts for all concrete mixing equipment. Core wear parts and electrical components are well stocked for fast delivery. Original parts enable quick replacement and repair, ensuring stable equipment performance, extended service life and safe operation.
Long-term Technical Support
We offer lifelong professional technical support for all clients. We provide technical consultation, routine maintenance guidance, parameter adjustment and equipment upgrade solutions throughout the entire service cycle.
Contact Us
Ready to upgrade your construction projects with our premium concrete batching plant solutions? Contact us today for a free professional consultation and customized quotation. Our experienced engineering and sales team is ready to support you throughout every step of your purchase and cooperation.
