Planetary Concrete Mixer MP Series | High Efficiency Precast & Block Making Mixer
Efficient & Uniform Mixing Performance
Adopts the forced stirring principle, which can fully and evenly mix cement, aggregate, sand, water and other raw materials. It ensures high mixing uniformity without dead corners, stably meets high-standard mixing requirements, and effectively guarantees the quality of concrete.
Flexible & Convenient Operation
Features flexible operation, easy movement and simple daily maintenance. The humanized structural design reduces the intensity of manual operation, improves the efficiency of daily use, and is easy to operate and master.
Stable & Reliable Operation
Adopts scientific structural design and high-quality core components, which can realize large-scale and continuous stable operation. It effectively reduces the equipment failure rate, ensuring long-term stable operation and providing reliable support for production.
- Overview
- Specifications and Parameters
- Application Scenarios
- FAQ
- Recommended Products
Product Overview
The planetary concrete mixer adopts the forced stirring principle, which can fully mix raw materials such as cement, aggregate, sand and water, ensuring uniform mixing quality and stable production of various grades of concrete. It is equipped with high-quality stirring components and a scientific structural design, which effectively avoids dead corners in mixing and ensures the consistency and uniformity of materials. The mixer has the advantages of flexible operation, easy movement and simple daily maintenance, with a sturdy structure that can realize large-scale and continuous stable operation. Its drive system and stirring structure are reasonably designed, which can maintain stable performance during long-term operation, reduce failure rate, and ensure efficient and reliable operation of the equipment itself. It adopts high-wear-resistant parts and precision manufacturing technology, which enhances the durability and service life of the equipment, and can stably meet the high-standard mixing requirements of various engineering projects.
Boasting the unique planetary stirring trajectory, the equipment achieves three-dimensional and omnidirectional material mixing that outperforms traditional mixing equipment. It is compatible with diverse materials including high-strength concrete, refractory mortar, and precast concrete materials, featuring strong production compatibility. Meanwhile, the optimized power operation system effectively reduces energy consumption, achieving energy-saving and environmentally friendly production. It can perfectly adapt to complex and harsh construction working conditions, providing consistent and high-quality mixing output for various engineering projects.
Specifications and Parameters
| Model | MP500 | MP750 | MP1000 | MP1250 | MP1500 | MP2000 | MP2500 | MP3000 | MP4000 | MP4500 | MP5000 | MP6000 |
| Filling Volume(L) | 750 | 1125 | 1500 | 1875 | 2250 | 3000 | 3750 | 4500 | 6000 | 6750 | 7500 | 9000 |
| Output Volume(L) | 500 | 750 | 1000 | 1250 | 1500 | 2000 | 2500 | 3000 | 4000 | 4500 | 5000 | 6000 |
| Mixing Power(Kw) | 18.5 | 30 | 37 | 45 | 55 | 75 | 90 | 110 | 160 | 185 | 220 | 250 |
| Mixing Star*Mixing Blade | 1*2 | 1*3 | 2*2 | 2*2 | 2*2 | 3*2 | 3*3 | 3*3 | 3*3 | 3*3 | 3*3 | 3*3 |
| Discharging Power(Kw) | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
| Weight(Kg) | 2500 | 3500 | 5500 | 6000 | 6500 | 8500 | 10500 | 11000 | 16500 | 18500 | 21000 | 25000 |
Application Scenarios
High-Grade Concrete Production
Suitable for high-grade, high-precision concrete production. Its efficient and uniform mixing performance ensures consistent concrete quality, meeting the strict strength and compactness requirements of high-standard engineering.
Precast Component Manufacturing
Ideal for precast concrete component production (e.g., beams, slabs, columns). Its stable operation and uniform mixing effect guarantee the qualification of precast products.
Special Building Materials Mixing
Applicable to mixing special building materials such as lightweight aggregate concrete and fiber-reinforced concrete. The forced stirring mode ensures full blending of special raw materials.
Small-to-Medium-Scale Construction Projects
Suitable for on-site mixing in small-to-medium-scale construction. Its flexible movement and easy operation enable convenient deployment in different construction areas, improving on-site work efficiency.
Advantages：
Planetary mixing system ensures 100% homogeneous mixing
No dead angle inside mixer, higher mixing efficiency
Suitable for dry, semi-dry, and wet concrete
Heavy-duty structure with long service life
Easy maintenance and low operating cost
Widely used in high-end concrete production
FAQ
Q: What factors affect the mixing uniformity of the planetary mixer?
A: It is mainly affected by the rotation speed of the mixing blade, the gap between the blade and the mixing tank, and the feeding speed/proportion, ensuring no mixing dead angles.
Q: How to extend the service life of the planetary mixer's core components?
A: Regularly clean the mixing tank and blades after use, check the wear of core components (blades, seals) regularly, and replace worn parts in a timely manner; avoid overloading operation.
Q: Can the planetary mixer be customized according to production needs?
A: Yes. It can adjust mixing speed, mixing time and feeding mode according to concrete grade, production scale and material type, and can be matched with the batching system.
Q: What is the advantage of the planetary mixer compared with ordinary mixers?
A: It adopts a dual-rotation (planetary) mixing structure, with no mixing dead angles, more uniform mixing, higher efficiency, and can meet high-standard engineering requirements.
Q: What are the key points of daily maintenance of the planetary mixer?
A: Clean the equipment in time after use; regularly inspect the tightness of the drive part and the wear of the blade; ensure stable power supply and calibrate mixing parameters regularly.
Minimum order quantity ：
1 set
Service Assurance ：
Installation & Commissioning Support
Professional technical team provides on-site installation and commissioning guidance, ensuring the equipment operates stably and efficiently, and offers detailed operation training for operators.
Wear Parts Supply
Sufficient stock of original wear parts (mixing blades, seals, etc.) is available, with fast delivery to minimize equipment downtime.
24/7 Technical & After-Sales Support
24-hour online technical consultation and fault response are provided. Remote guidance is available for operation and failure issues to ensure continuous production.
Lifelong Technical Support
Lifelong free technical consultation is offered, including equipment maintenance, parameter adjustment and fault troubleshooting, to extend equipment service life.
