High Efficiency Quick Installation Foundation Free Concrete Batching Plant
Foundation-Free Design: Starts production in 10-15 days without foundation work, saving time and labor costs.
No Civil Construction Needed: Reduces project delays and eliminates the need for expensive civil work.
Flexible Relocation: One plant can be used for multiple projects, improving equipment utilization and ROI.
Cost-Effective Solution: Saves up to 30% total investment by eliminating foundation work and reducing labor costs.
We provide layout design, equipment configuration, installation guidance and after sales support.
- Overview
- Specifications and Parameters
- Application Scenarios
- FAQ
- Recommended Products
Product Overview
The Foundation-Free Concrete Batching Plant is an innovative integrated concrete production equipment that eliminates the need for traditional complex concrete foundations. It adopts I-beam steel structures for integrated support, featuring a scientific and stable structural design that ensures reliable operation performance.
This no-foundation batching plant significantly reduces on-site installation time and civil engineering costs, as it requires no extra foundation construction and can be quickly deployed on flat, compacted ground. Its modular integrated design combines aggregate batching, precise weighing, forced mixing, automatic control and unloading into one compact unit, with reasonable layout and small floor occupation.
Equipped with a high-performance mixing system and intelligent automatic control, it ensures uniform mixing quality and accurate proportioning, minimizing manual intervention. Made of high-strength wear-resistant materials, the plant boasts stable performance, long service life and easy daily maintenance, perfectly meeting the high-efficiency concrete production needs of modern construction.
Specifications and Parameters
| Model | MHZS60 | MHZS90 | MHZS120 | MHZS150 | MHZS180 | MHZS240 | MHZS270 | MHZS300 |
| Capacity | 60m³/h | 90m³/h | 120m³/h | 150m³/h | 180m³/h | 240m³/h | 270m³/h | 300m³/h |
| Host | JS1000 | JS1500 | JS2000 | JS2500 | JS3000 | JS4000 | JS4500 | JS5000 |
| Host Capacity | 1.0 m³ | 1.5 m³ | 2.0 m³ | 2.5 m³ | 3.0 m³ | 4.0 m³ | 4.5 m³ | 5.0 m³ |
| Batching Machine | PLD1600 | PLD2400 | PLD3200 | PLD4000 | PLD4800 | PLD6400 | PLD7200 | PLD8000 |
| Number of Aggregate Bins | 3-4 | 3-4 | 3-4 | 3-4 | 4-6 | 4-6 | 4-6 | 4-6 |
| Aggregate Bin Capacity | 24m³ | 28m³ | 35m³ | 45m³ | 45m³ | 60m³ | 70m³ | 80m³ |
| Discharge Height | 4.0m | 4.0m | 4.2m | 4.2m | 4.2m | 4.2m | 4.2m | 4.2m |
| Total Power | 90KW | 120KW | 150.5KW | 168.5KW | 206.5KW | 256.5KW | 283.5KW | 313.5KW |
| Overall Dimensions | 17.53.03.1m | 17.5(20.5)3.03.2m | 18.0(21.0)3.03.2m | 18.5(21.5)3.03.2m | 19.5(23.5)3.03.2m | 24.53.03.2m | 25.53.03.2m | 26.53.03.2m |
Application Scenarios
 |
Remote-Area, Medium-to-Long-Term Infrastructure Project Sites |
|
Municipal Engineering Projects |
 |
|
|
Suburban, Medium-to-Long-Term Infrastructure Projects |
Advantages：
We provide a foundation-free concrete batching plant designed for fast installation and flexible use.
This solution helps contractors and project owners reduce installation time, lower investment cost and improve project efficiency.
From equipment supply to layout design and installation guidance, we provide a complete solution for your concrete production needs
FAQ
Q：Do I need a concrete foundation for this plant?
A：No, this batching plant is designed for foundation-free installation. Only a flat and compacted ground is required.
Q：Can the plant be relocated?
A：Yes, the modular design allows easy dismantling and relocation for multiple projects.
Q：Do you provide layout design before purchase?
A：Yes, we offer free layout design based on your project requirements to help you plan your site clearly.
Q：Do you provide overseas installation service?
A：We can provide online guidance and technical support. If needed, engineers can also be arranged depending on the project.
Q：How can I get a quotation quickly?
A：Please send us your project details such as required capacity, site condition and destination port. We will provide a suitable solution and quotation as soon as possible.
Minimum order quantity ：
1 set
Service Assurance ：
We deliver all-round after-sales guarantee for concrete batching and mixing equipment, covering professional service, technical backup, parts supply and timely maintenance, to keep your equipment running steadily all the time.
Professional Installation and Commissioning
Professional engineers provide one-stop on-site installation, assembly and commissioning upon equipment arrival. We fine-tune operational parameters to bring the unit to optimal working condition in minimal time.
Timely Fault Maintenance and Repair
We implement a rapid after-sales response system. Our technical team offers immediate remote guidance to resolve minor equipment faults online. For complex malfunctions requiring on-site service, we arrange professional engineers for prompt arrival, minimizing downtime and project losses.
Original Factory Spare Parts Supply
We provide 100% original factory spare parts for all concrete mixing equipment. Core wear parts and electrical components are well stocked for fast delivery. Original parts enable quick replacement and repair, ensuring stable equipment performance, extended service life and safe operation.
Long-term Technical Support
We offer lifelong professional technical support for all clients. We provide technical consultation, routine maintenance guidance, parameter adjustment and equipment upgrade solutions throughout the entire service cycle.
